KNAUF Therm PRO Facade / Roof / Floor EPS 80 λ 37

KNAUF Therm PRO Facade / Roof / Floor EPS 80 λ 37

MARKING BY STANDARD

KNAUF Therm PRO Facade / Roof / Floor EPS 80 λ 37 Styrofoam panels are marked with the following code in accordance with EN 13163: 2012 + A1: 2015 EPS –EN 13163-T (1) -L (2) -W (2) -S (2) -P (5) -BS125-CS (10) 80-DS (N) 2-DS (70, -) 1-TR100

λD Thermal conductivity W/(mK) ≤ 0,037
Shape Rectangular or milled
Dimensions 1000 x 500mm max
wym.: 4000 x 1200mm
Compressive stress level at 10% relative deformation (kPa) CS(10)80 (≥ 80)
Fire resistance Self-extinguishing
Fire resistance class E
Flexural strength level (kPa) BS125 ( ≥ 125)
Tensile strength perpendicular to surface (kPa) TR100 ( ≥ 100)
